Product Code : SCM-01
Product Description

Static Charge Meter

The Static Charge Meter is a non contact, low cost, light weight static monitoring and locating instrument. It utilises a centre-zero meter display to indicate the magnitude and polarity of the electrostatic charge.

The instrument has good directional sensitivity and is ideal for measuring electric charges encountered in critical electronic assembly and storage areas as well as Antistatic Work stations. It can also be used for Plastics, Paper, Textiles, Food,

Explosives and Pharmaceutical Industries.

The unit gives direct readings of electrostatic potentials on any surface, when held at a distance of 2.5 cms. However, virtually any electrostatic potential can be measured by proportionately increasing the distance from the meter to the charged object.

Specifications

Measurement Range

+/- 5kV At 2.5 CMS

Measurement Accuracy

+/-10%

Indication

Analog Dial

Test actuation

Press To Read

Power Supply

9 Volt Battery

Dimensions

125 x 65 x 35 mm

Weight

180 GMS (With Battery)

Calibration

Recommended every 12 months

Warranty

12 Months

Optional

Instrument Carry case
