Human Body Volatge Checker

Human Body Volatge Checker
Human Body Volatge Checker
Product Code : SC-01
Product Description

Human Body Voltage Checker

Human body voltage checker is a new and unique visual method of detecting how much static charge a person is carrying. The unit can be wall mounted outside the ESD protected area to avoid charged persons unknowingly entering.

The meter must always be grounded to produce an accurate measurement. But more importantly to allow the operator to discharge to a safe handling limit. Touch the Touch to test, and watch the LIQUID CRYSTAL DISPLAY indicated between 0 to 1999V of the static charge +/- Polarity.

Specifications

Power Supply

9V Battery

Accuracy

+/-10%

Resolution

1 Volt

Low Battery Indication

By LCD Display

Test Actuation

Touch to Test

Dimensions

135 x 70 x 25 mm

Weight

150 Gms (With Battery)

Calibration

Recommended every 12 months

Warranty

12 Months

Accessories

1 Meg Ohm Ground Cord, Instruction Board & Carry Case

APPLICATION

Static checker can be used to detect how much static a person is carrying.

Will indicate if wrist straps and coil cords are functioning, ground leads, bounding plugs, heel straps, custom floors, Static Spray Coating, etc.
